Liver Transplantation for Unresectable Hepatic Alveolar Echinococcosis

Alveolar echinococcosis is a parasitic disease caused by Echinococcus multilocularis larvae that most commonly affects the liver [1–6] forming a tumor-like injury, which possesses the ability to infiltrative growth, invasion of the main vessels of the portal and caval systems, biliary ducts, adjacent organs and tends to form distal metastases by hematogenic or lymphogenic way [1–4, 6]. Endemic regions of alveolar echinococcosis are Western Siberia, Far East, Central Asia, Central Europe, Alaska, North Canada, China [6, 7].

The only way of liver alveococcosis treatment nowadays is surgical [4, 8]. However, the disease is often diagnosed in the late stages when the parasite reaches large sizes or mechanical jaundice develops, since patients do not have any symptoms of the disease in the early stages when resection of the liver is feasible [4, 6, 9–11]. Due to these factors, operations for alveolar echinococcosis are characterized by a large extent, are connected with reconstructive and plastic interventions on the great vessels and biliary ducts [12]. Standard radical liver resection becomes hardly feasible in the situations with a large volume of the damaged parenchyma, invasion of the afferent and/or efferent hepatic vessels, retrohepatic segment of the inferior vena cava (IVC), and the right atrium [4, 6, 13, 14], often requiring orthotopic liver transplantation, which enables complete removal of the parasitic tumor, resection and plastic surgery of the great vessels and may be regarded as a principle method of the radical treatment in the so-called unresectable alveolar echinococcosis of the liver [3, 6, 15–17].

The aim of the investigation was to assess the immediate and long-term results of the liver transplantation in patients with unresectable hepatic alveolar echinococcosis.

Materials and Methods. 22 liver transplantations were performed in the Center for Surgery and Transplantology of the State Research Center — A.I. Burnazyan Federal Medical and Biophysical Center between January 2011 and December 2016 for unresectable liver disease. Liver segments (the right liver lobe in all cases) from living related donors were transplanted to 21 patients; a postmortal donor liver was transplanted to 1 female patient. Parasitic invasion of the IVC was found in 16 patients (72.7%), invasion of the right atrium in 7 patients (31.8%) (Figure 1).

Figure 1. CT image of unresectable liver alveococcosis: (a) parasitic liver damage with invasion of hepatic venous confluence, inferior vena cava (IVC), left lobe portal vein; (b) parasitic liver damage with invasion of IVC at the level of its entry to the right atrium; (c) parasitic liver damage with invasion of hepatic venous confluence and IVC; (d) parasitic damage of both hepatic lobes with extension to the caval hilum, involvement of hepatic veins, right and left portal veins, IVC, left hepatic artery, right adrenal gland, invasion of the right kidney; (e), (f) parasitic liver damage with involvement of the hepatic caval hilum, hepatic veins, IVC, right portal vein, right hepatic artery, bifurcation of the intrahepatic bile ducts, great vessels, antral part of the stomach

18 patients underwent nonradical surgical treatment in the past (nonradical liver resection, morcellation of alveococcus, drainage of the alveococcus decay cavity, and others).

Jaundice on admission was noted in 7 patients (31.8%).

There were 15 women and 7 men among the patients aged from 28 to 51 years (median 36).

The study complies with the Declaration of Helsinki (the Declaration was passed in June 1964, Helsinki, Finland, and revised in October 2000, Edinburg, Scotland) and was performed following approval by the Ethic Committee of State Research Center — A.I. Burnazyan Federal Medical and Biophysical Center. Written informed consent was obtained from every patient.

All operations were done in the R0 variant (Figure 2). Invasion of the parasitic process to the adjacent organs was found in 14 patients (63.6%) and, in this connection, resection of the diaphragm was performed in 10 patients, right-sided adrenalectomy in 1 patient, resection of the pericardium in 4 patients, 1 stomach resection, 1 duodenum resection, 2 nephroadrenalectomy on the right.

Figure 2. Transplantation of the right hepatic lobe with resection and prosthetic replacement of the inferior vena cava (IVC) with PTFE-conduit: (a) hepatectomy with resection of IVC, right diaphragm dome; (b)–(e) transplantation of the right hepatic lobe from a living related donor, IVC plasty using PTFE-conduit; (f) bilobar parasitic liver invasion (preparation). PV: portal vein; HA: hepatic artery

No metastases of alveococcus were revealed.

Great vessels plasty, including IVC, was done using PTFE-conduits if autoplasty was not feasible, in case of the right atrium resection right atrium-caval prosthetic surgery with PTFE-conduits was performed (See Figure 2).

Dissection of the hepatic parenchyma was accomplished by bipolar coagulation with targeted ligation of the vascular and ductal structures.

Postoperative liver failure was determined in compliance with the criteria of liver function evaluation after transplantation suggested by Olthoff et al. [18].

The rate and severity of biliary complications in the postoperative period were assessed according to the ISGLS recommendations [19].

All patients received Albendazole for 6 months in the postoperative period.

Quantitative data are presented in the form of Median (interquartile range). The results of the investigation were processed using Statistica 10.0 applied program package (StatSoft Inc., USA) [20].

Results. The duration of the operation amounted to 430 (390–480) min, the volume of the intraoperative blood loss was equal to 1,500 (1,300–2,200) ml, the cold ischemia duration was 30 (25–45) min.

The morbidity rate of postoperative complications was equal to 45.4%. Among them 4 patients were with biliary complications (Grade A, B; ISGLS, 2011); 2 patients with intra-abdominal bleeding requiring relaparotomy and bleeding arrest; 2 cases of hospital pneumonia; 3 cases with hydrothorax demanding drainage or US-controlled puncture of the pleural cavity; and 2 patients with ascites requiring US-controlled drainage of the abdominal cavity.

In 3 patients bilomas found in the abdomen required US-controlled drainage, in 1 patient transdrainage bile leakage was noted.

An intrapleural bleeding developed in 1 patient and required relaparotomy, sanation and hemostasis, later there formed a hematoma of the pleural cavity which was treated by the US-controlled drainage. A crisis of transplant rejection developed in 1 patient who had to be administered a pulse therapy.

Mortality rate amounted to 4.5%: one woman died of profuse gastrointestinal bleeding from acute stress ulcers of the stomach and duodenum on day 16 after the operation.

The length of hospital stay after liver transplantation amounted to 20 (15–23.5) bed days. Long-term survival after liver transplantation was 100%, maximal follow-up period lasted 58 months.

Discussion. Alveolar echinococcosis of the liver is a parasitic disease resembling malignant tumor in its growth and extension [1–6]. If not radically treated, the mortality rate is usually 90% within 10 years after being diagnosed [3], however, radical surgical intervention is feasible only in 35% of these patients due to a late diagnosing of the disease [3, 4, 6, 13, 14, 21]. The main and frequently the only way of radical treatment of patients with unresectable liver alveococcosis is liver transplantation [3, 6, 15–17, 22], however, the technical complexities of the operation due to parasitic invasion of the great vessels, IVC, right atrium, adjacent structures and organs, the previous non-radical surgical interventions, as well as shortage of donor organs, limit the feasibility of liver transplantation.

Little experience has been acquired in the world in the field of liver transplantation for unresectable alveococcosis. It is likely to be connected with the epidemicity of the disease — Echinococcus multilocularis is extremely rarely encountered in the countries with the developed program of liver transplantation. In our Center 22 liver transplantations have been performed in the patients with unresectable alveococcosis, a liver fragment was transplanted from a living related donor to 21 of them. The data presented seem to be the largest single-center experience in the world.

The results obtained enable us to declare the necessity and feasibility of the radical surgical treatment of unresectable liver alveococcosis regardless of the invasion of the great vessels, liver hilum, IVC, right atrium and adjacent structures and organs. Reconstruction of IVC after hepatectomy with the resection of the retrohepatic IVC segment, involved in the pathological process, is feasible by means of synthetic PTFE-conduits.

Conclusion. Liver transplantation with resection and reconstruction of the great vessels, including resection of inferior vena cava, and even the right atrium, may be the only radical method of treating unresectable hepatic alveolar echinococcosis making it possible to provide satisfactory immediate and long-term results of the surgical treatment of patients seemingly doomed to death. These interventions should be performed only in highly specialized centers with a developed program of surgical hepatology and liver transplantation.

Study Funding and Conflicts of Interest. The work was not supported by any source, and there are no conflicts of interest related to this study.
